Home > SMD 7020 LED > Details

SMD 7020 LED

SMD 7020 LED White TV backlight 0.5W

Specifications
Band：Yuanke
Name：7020 Pure white
Model：YK-7020W
CCT ：6000-6500K
Lumen：55-60LM
Ra：>70
Power：0.5W
Current：150MA
Voltage：3.0-3.2V
Deg：120
Raw material：Copper bracket / pure gold wire
Quantity：4000pcs/reel
Size：7.0*2.0*0.7MM
Click to download the datasheet
